Overview
Voodoo UV is the UV-printable version of the classic Voodoo blockout fabric, offering enhanced versatility across multiple print platforms. Designed with a black back for excellent opacity, it delivers strong, vibrant print results while maintaining full light control.
Constructed from a durable polyester blend with a knitted structure, Voodoo UV supports a wide range of ink technologies, making it a flexible solution for display, frontlit, and blockout applications.
Key Features
- UV printable textile for expanded application use
- Black back for effective blockout performance
- Compatible with multiple print technologies
- Extra wide format – up to 505 cm
- Durable polyester + PA knitted construction
- Suitable for cold and hot cutting
- Fire-rated and environmentally certified
Applications
- Display graphics
- Frontlit applications
- Blockout displays
Ink Compatibility
- Sublimation Direct
- Sublimation Transfer
- UV
- Latex
- Solvent
Material & Technical Specifications
| Property | Specification |
|---|---|
| Material | Polyester + PA (Knitted) |
| Weight | 260 gsm |
| Thickness | 0.44 mm |
| Maximum Width | Up to 505 cm |
| Shrinkage | 0% |
| Light Transmission | ≤ 1% |
| Stretch | Length ≤ 1.6% (±0.8) / Width ≤ 1.8% (±1) |
Print & Finishing Notes
- Print side: IN
- Cutting methods: Cold / Hot
- Calender settings: 205°C at 0.65 m/min
Certifications
- REACH Compliant
- FR EN 13501
- FR NFPA 701
- FR B1
- FR M1
- OEKO-TEX®
- GRS (Global Recycled Standard)
Important Information
The technical data provided is based on tests believed to be reliable and is for guidance only. It does not constitute a guarantee or warranty. Users should independently assess suitability for their intended application. All specifications are subject to change without notice.
Need Help?
For pricing, samples, or more information:
Pyramid Display Materials
📧 sales@pyramid-display.co.uk
🌐 www.pyramid-display.co.uk
